HFCG SERIES ROLLER PRESS
HFCG Series of Roller Press is high efficiency energy saving grinding equipment which has developed by Hefei Research & Design Institute [CNBM(Hefei) Powder Technology Equipment Co.,Ltd.] with independent intellectual property right. These research and development projects such as "Roller Press Grinding New Process and Equipment" and " Roller Press Grinding Technology and Equipment For Energy Conservation" has provided better solutions for grinding powder in the mining, building materials industry, and they were rewarded silver medals respectively at the state level and at the sector level. The grinding system with HFCG roller press is adopted, of which main technical and economic indicators such as power consumption and physical features have reached the international advanced level at nowadays. The total sales of HFCG roller press has reached 1600 sets, ranking first in the world.
Characteristics
- The advanced structure of roller sleeve and the process of roller surface wear resistance could make the service life of roller surface between 8000 and 30000hrs.
- The hydraulic system could operate more reliable with the design of flexible constant pressure and unique structure.
- Roller press runs more stably with a compact torque supporting unit.
- The advanced detection and automation control system ensure a safe and smooth running of roller press.
|
Series |
Model |
Diameter of roller(mm) |
Width of roller(mm) |
Motor Power(kW) |
Feeding size(mm) |
Throughput (t/h) |
|
120 Series |
HFCG120-45 |
1200 |
450 |
2*200 |
≤50 |
125~150 |
|
HFCG120-50 |
1200 |
500 |
2*250 |
≤50 |
140~165 |
|
|
HFCG120-80 |
1200 |
800 |
2*250 |
≤25 |
85~100 |
|
|
140 Series |
HFCG140-65 |
1400 |
650 |
2*500 |
≤60 |
240~295 |
|
HFCG140-70 |
1400 |
700 |
2*500 |
≤60 |
260~315 |
|
|
HFCG140-80 |
1400 |
800 |
2*500 |
≤60 |
295~360 |
|
|
150 Series |
HFCG150-100 |
1500 |
1000 |
2*710 |
≤60 |
415~500 |
|
160 Series |
HFCG160-120 |
1600 |
1200 |
2*900 |
≤70 |
580~670 |
|
HFCG160-140 |
1600 |
1400 |
2*1120 |
≤70 |
680~780 |
|
|
180 Series |
HFCG180-160 |
1800 |
1600 |
2*1600 |
≤70 |
950~1100 |
|
200 Series |
HFCG200-180 |
2000 |
1800 |
2*2000 |
≤70 |
1450~1700 |
Mining Industry--Roller Press (HFKG)
|
Series |
Model |
Diameter of roller(mm) |
Width of roller(mm) |
Installed Power （Max,kW) |
Feeding size(mm) |
Throughput (t/h) |
|
140 Series |
HFKG140-50 |
1400 |
500 |
2*400 |
≤30 |
360 |
|
150 Series |
HFKG150-60 |
1500 |
600 |
2*500 |
≤30 |
470 |
|
HFKG150-80 |
1500 |
800 |
2*630 |
≤30 |
620 |
|
|
160 Series |
HFKG160-100 |
1600 |
1000 |
2*900 |
≤30 |
830 |
|
HFKG160-120 |
1600 |
1200 |
2*1120 |
≤35 |
1000 |
|
|
HFKG160-140 |
1600 |
1400 |
2*1250 |
≤35 |
1170 |
|
|
180 Series |
HFKG180-100 |
1800 |
1000 |
2*1000 |
≤35 |
940 |
|
HFKG180-120 |
1800 |
1200 |
2*1250 |
≤35 |
1120 |
|
|
HFKG180-140 |
1800 |
1400 |
2*1400 |
≤35 |
1300 |
|
|
200 Series |
HFKG200-120 |
2000 |
1200 |
2*1600 |
≤40 |
1420 |
|
HFKG200-160 |
2000 |
1600 |
2*2000 |
≤40 |
1900 |
|
|
220 Series |
HFKG220-160 |
2200 |
1600 |
2*2240 |
≤40 |
2100 |
|
240 Series |
HFKG240-180 |
2400 |
1800 |
2*3150 |
≤40 |
2660 |
1. Product Size could satisfy the requirements which is in the range 0.045mm to 3mm.
2. The above two tables only include a part of models for reference, we also provide many other specification equipments which could be used in nonferrous metallurgy and industrial waste. Please contact us for more information.
